CWM Grinding Machine

Name:CWM Grinding Machine

Model: CWM-250

Granularity:2-40um

Capacity:450-500kg/h

Power:22kw

Rotation Speed:2940rpm

Size:1560*560*1620mm

Weight: 700kg

Inquire Now

Description

*Description:

CWM Grinding Machine also be called CWM Superfine Mill may be widely used in superfine processing of foodstuff, paint, plastic, color pulp, coatings, dye-stuff and other materials hard to process, especially suited for more oily materials such as peanut butter, sesame, rapeseeds, sunflower seeds, mustard, cocoa bean, almond etc. It is welcome by more and more users due to its high output, superfine-process ability and low temperature rise.

*Principle of operation

By means of the relative movement of the special geometric shaped rotor and stator in high revolving speed, materials pushed by feed propeller enter into the variable annular clearance, will be subjected to strong centrifugal, sheering and milling force. Thus a satisfactory super fineness may be attained.

*Technical data

Model	Granularity ( um )	Capacity ( kg/h )	Power ( kw )	Rotation Speed( rpm )	Dimension ( mm )	Weight ( kg )
CWM-250	2 - 40	450-500	22	2940	1560×560×1620	700

Peanut Butter Production Line, CWM Grinding Machine, Peanut Butter Grinding Machine, Peanut Paste Grinding Machine, Peanut Butter Making equirpment, CWM Superfine Mill
